14 months Warranty
Product Highlights
- ONE-STOP Fiber Optic Superstore
- High-quality pre-sales, including solution customization, sample request, test reports, and perfect warranty & return policies allow you to enjoy worry-free experience.
- Short lead time, Deliver on time, Strict quality checking before shipment.
- Our professional sales team win the reputation in home and abroad with the outstanding service and high quality products.
- 24/5 around-the-clock customer service and technical support for tackling any complex issue anytime.
Fiber Parameters
| Items | G652D |
| Attenuation | 1310nm≤0.36 dB/km 1550nm≤0.22 dB/km |
| Chromatic Dispersion | 1310nm≤3.5 ps/nm.km 1550nm≤18 ps/nm.km 1625nm≤22 ps/nm.km |
| Zero Dispersion Slope | ≤0.092 ps/nm.km |
| Zero Dispersion Wavelength | 1300~1324 nm |
| Cut-off Wavelength (λcc) | ≤1260 nm |
| Attenuation vs.Bending(60mmx100turns) | (30mm radius 100ring) ≤0.1 @1625nm |
| Mode Field Diameter | 9.2+0.4 at 1310nm |
| Core-Clad Concentricity | ≤0.5 um |
| Cladding Diameter | 125+1 um |
| Cladding Noncircularity | ≤0.8% |
| Coating Diameter | 245+5 um |
| Proof Test | ≥0.69 Gpa |
Mechanical and Environmental Characteristics
| Tensile Loading Test | #Test method:IEC 60794-1-E -.Long-tensile load: 350N -.Short-tensile load: 800N -.Cable length:≥50m |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| Crush Resistance Test | #Test method:IEC 60794-1-E3 -.Long load:300 N/100mm -.Short load:1000 N/100mm -.Load time: 1 minutes |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| lmpact Resistance Test | #Test method:IEC 60794-1-E4 -.Impact height:1 m -.Impact weigh:450 g -.Impact point:≥5 -.Impact frequency:≥3/point |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| Repeated Bending | #Test method:IEC 60794-1-E6 -.Mandrel diameter: 20D (D = cable diameter) -.Subject weight: 15kg -.Bending frequency: 30 times -.Bending speed: 2s/time |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| Torsion Test | #Test method:IEC60794-1-E7 .Length:1m Subject weight:25kg -.Angle:±180 degree .Frequency:210/point |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| Water Penetration Test | #Test method:IEC 60794-1-F5B -.Height of pressure head: 1m -.Lenath of specimen: 3m -.Test time: 24 hours |
-.No leakage through the open cable end |
| Temperature Cycling Test | #Test method:IEC 60794-1-F1 -.Temperature steps: +20°C -40°C、+70°C、+20°C -.Testing Time:24 hours/step -.Cycle index:2 |
-.Attenuation increment@1550nm:≤0.1dB -.No jacket cracking and fiber breakage |
| Drop Performance | #Test method:IEC60794-1-E14 -.Testing length: 30cm -.Temperature range: 70±2°C -.Testing Time: 24 hours |
-.No filling compound drop out |
What Does One-Stop Service Mean For You?
14 months Warranty
Our products are strictly inspected to ensure they are working properly before shipment. At the same time, our warranty is higher than industry standards, up to 14 months. Customers only need to run their own business, and we will handle product issues for you.
We have a professional technical team that can help you solve most software and hardware problems. We are also familiar with FTTH solutions and will assist you 24 hours a day to solve your and your customers' problems.
How to Ship My Products?
We ships orders by international couriers, including DHL, FedEx, EMS, UPS, TNT and Aramex (mainly for Africa and Middle East). You can refer to the The Shipping Methods Guide.
How to Save on Shipping?
To save your shipping cost, we suggests you buy all items in one time in one order. This will minimize the shipping cost for each item and save your cost. If you can wait much longer, please choose the standard shipping method. It will be much cheaper than using express shipping.
Can You Ship To My Country?
Definitely, we can ship to your country. We can ship orders to worldside.
Note: You should be clear about the import tax situation in your own country.
