GJ.012 BOU350 Handheld Optical Laser Source 1310-1625nm
The GJ.012 BOU350 handheld optical laser source outputs one to three wavelengths from one port with 270Hz, 1KHz and 2KHz modulation and a stable FC/PC output.
Description
Overview
The GJ.012 BOU350 is a handheld optical laser source that outputs one to three wavelengths from a single port, with high stabilization and a built-in optic isolator.
It offers 270Hz, 1KHz and 2KHz modulation output, an energy save mode and Auto-Wave ID output that pairs with a TriBrer OPM, and runs from AA batteries or an AC/DC adapter.
GJ.012 BOU350 Key Features
- Up to three wavelengths output from a single port
- High stabilization with a built-in optic isolator
- 270Hz, 1KHz and 2KHz modulation output
- Energy save mode for longer field operation
- Auto-Wave ID output that pairs with a TriBrer OPM
- Handheld housing measuring 160mm * 75mm * 32mm
GJ.012 BOU350 Specifications
| Parameter | Specification |
|---|---|
| Model | M8 / M3 / S3 / S4 / S5 / S6 |
| Wavelength(nm) | 850 / 1300 / 1310 / 1490 / 1550 / 1625 |
| Stabilization* | 0.05dB / 1 hour; 0.1dB / 8 hours |
| Output Power | > – 6dBm @ 1310nm/1490nm/1550nm/1625nm / > -10 dBm @ 850nm/1300nm |
| Modulation | 270Hz, 1KHz, 2KHz |
| Connector | FC/PC (or customize) |
| Auto Power Off | No operation in 10 minutes (can be canceled), Low battery energy |
| Battery Charge | Yes |
| Power Supply | AA * 2 batteries or AC/DC power supply adapter |
| Size(H*W*D) | 160mm * 75mm * 32mm |
| Weight | About 180g |
| Storage Temperature | -20 — +60 , < 90%RH |
| Operating Temperature | -10 — +50 , < 90%RH |
Applications
- Insertion loss testing of single and multi-wavelength fibre links
- Pairing with an optical power meter for end-to-end loss measurement
- Fibre identification and tracing with modulated tone output
- Commissioning and maintenance of SM and MM networks
