NK1000 Optical Time Domain Reflectometer module
NK1000 OTDR module card for optical cable monitoring systems, offering 42dB SM dynamic range, SM/MM/online test, APD protection and a plug and play Ethernet control interface.
Description
Overview
The NK1000 series OTDR module provides a compact, cost-effective and high-performance card solution for optical cable monitoring systems. The Ethernet port is used as the control interface for secondary development.
The PC or embedded system sends the test command to the module and receives the returned results to complete all the work. The module can be embedded into the base station or optical fiber communication link for real-time remote monitoring of the health status of the optical cable.
NK1000 Key Features
- The max dynamic range of SM can reach 42dB
- Support SM/MM/online test
- Support light detection and APD protection
- Plug and play Ethernet interface
- Support the secondary development of users
- Optical fiber link online test
NK1000 Specifications
| Parameter | Specification |
|---|---|
| Max dynamic range of SM | 42dB |
| Test support | Support SM/MM/online test |
| Interface | Standard Ethernet interface |
| Detection | Light single automatic detection |
| Protection | With APD protection |
| Development | Support the secondary development of users |
| Monitoring | Optical fiber link online test |
| Environmental adaptability | – 10℃~+50℃ |
Applications
- Optical cable monitoring systems for backbone networks
- Metropolitan area network and access network maintenance
- Real-time remote monitoring of the health status of optical cables
- Embedded integration into base stations and fiber communication links
