KU-1008G 10-Port Gigabit PoE Switch – 8×PoE, 96W

The KU-1008G Gigabit PoE switch delivers 8 PoE ports and 2 uplink ports with a 24 Gbps switching capacity and a 96 W total power budget.

SKU： KU-1008G 分类： PoE Switch

Worry-Free After-Sales14-month warranty & responsive support

Efficient ProcurementOne-stop sourcing, fast turnaround

Fast Response Times24/7 expert technical support

Get wholesale pricing >>>

Description

Overview

The KU-1008G is a Gigabit PoE switch built for small networks that need full-speed links. It provides 8 × 10/100/1000 Mbps PoE ports and 2 × 10/100/1000 Mbps uplink ports in a compact 197 × 73.5 × 29 mm chassis.

PoE ports run up to 30 W each under IEEE 802.3at / 802.3af, with a total power budget of up to 96 W. The switching capacity is 24 Gbps and power comes from a 52V / 2.3A DC input.

KU-1008G Key Features

8 × 10/100/1000 Mbps PoE ports plus 2 × 10/100/1000 Mbps uplink ports
IEEE 802.3at / 802.3af with up to 30 W per PoE port
Total power budget of up to 96 W from a 52V / 2.3A DC input
24 Gbps switching capacity and support for up to 1236 VLANs
Compact 197 × 73.5 × 29 mm desktop housing

KU-1008G Specifications

Technical Specifications

Parameter	Specification
PoE Ports	8 × 10/100/1000 Mbps
Uplink Ports	2 × 10/100/1000 Mbps
DC Input	52V / 2.3A
Switching Capacity	24 Gbps
Power per PoE Port	≤30 W
Max Power Consumption	≤96 W
Number of VLANs	1236
PoE Standard	IEEE 802.3at / 802.3af
Dimensions	197 × 73.5 × 29 mm
Gross Weight	0.35 kg
Packing	40pcs/ctn

Deployment Scenarios

Gigabit IP camera systems where every camera link must run at full speed
Wi-Fi 5 and Wi-Fi 6 access points that need Gigabit uplinks
Desktop or shelf installations where a compact 197 × 73.5 × 29 mm unit is preferred

Packing & Shipping

Clients often worry about transit damage?

Our sturdy packaging puts those fears to rest. For different products we use waterproof film, foam protection, palletizing, wooden frame securing and cable reels. This ensures safe and reliable transport.
