X98H 4K Android TV Box – Allwinner H618, 4GB/32GB
The X98H is an Android 12 TV box with an Allwinner H618 chipset, 4GB RAM, 32GB ROM and HDMI 2.0a output whose H265 Main10 decoder reaches 4K@60fps or 6K@30fps.
Description
Overview
The X98H is an Android 12 TV box powered by an Allwinner H618 chipset in a Quad core ARM Cortex A53 configuration with a Mali G31 MP2 GPU. Its mainboard is designated YB882.
It pairs 4GB RAM with 32GB ROM, and its H265 Main10 decoder handles 4K@60fps or 6K@30fps. HDMI 2.0a carries the 4K 2K output, and the black plastic case measures 106x106x19mm.
X98H Key Features
- Allwinner H618 chipset with a Quad core ARM Cortex A53 CPU and a Mali G31 MP2 GPU
- Android 12 with Multi-Language support
- 4GB RAM and 32GB ROM, with 2GB and 16GB options
- H265 Main10 decoder up to 4K@60fps or 6K@30fps, with VP9 Profile 2 and AVS2 Jizhun
- HDMI 2.0a 4K 2K output plus CVBS with PAL/NTSC support
- Wi-Fi on IEEE802. a/b/g/n/ac /ax at 2.4GHZ , 5.8GHZ with BT5.0+
- 3 * USB 2.0 hosts, 1* TF Card and 1*Default 100M( optional 1000M) Ethernet
X98H Specifications
| Parameter | Specification |
|---|---|
| A-media ID/Mainboard model | YB882 |
| CPU | Allwinner H618, Quad core ARM Cortex A53 |
| GPU | Mali G31 MP2 |
| RAM | 4GB (2GB Optional) |
| ROM | 32GB (16GB Optional) |
| External storage | USB Storage Devices: Supported |
| Operating system | Android 12; Language: Multi-Language |
| Video | Video Decoder: H265 Main10@L5. 1 decoder up to 4K@60fps or 6K@30fps; VP9 Profile 2 decoder up to 4K @ 60fps; AVS2 Jizhun 10bit decoder up to 4K @ 60fps; H.264 BP/MP/HP@L4.2 decoder up to 4K@30fps; Multi-format 1080p @ 60fps video playback formats ,including H.264 BP/MP/HP , H 263 BP , VP8 , MPEG-1 MP/HL ,MPEG-2 MP/HL , MPEG-4 SP/ASP @ L5 , AVS +/AVS JizhunWMV9/VC1 , etc; Video encoder: H.264 BP/MP/ HP encoder up to 4K@25fps or 1080p @ 60fps JPEG snapshot performance of 1080p @ 60fps |
| Audio | MP3, AAC, WMA, FLAC, Ogg. |
| Image | HD JPEG、BMP、GIF、PNG、TIF |
| Wi-Fi | Type: IEEE802. a/b/g/n/ac /ax; Frequency: 2.4GHZ , 5.8GHZ; Antenna Type: Inside antennas |
| Bluetooth | BT5.0+ |
| Charge | DC connector: DC 5V- 2A |
| Video output | 1* 4K 2K Output, HDMI 2.0a; CVBS: Support PAL/NTSC |
| Audio | OPTCAL: 1 * SPDIF |
| Ethernet | 1*Default 100M( optional 1000M) |
| TF Card | External memory: 1* TF Card |
| USB port | USB Host: 3 * USB 2.0 |
| Upgrade | KEY: Update firmware |
| Others | RTC: Optional |
| Body Material | Plastic |
| Color | Black |
| Size | 106x106x19mm |
| Weight | 0.14 |
| Standard | CE /; RoHS / |
| Others | Optional / |
| Package contents | User manual *1; Gift Box *1; Remote control *1; HDMI external cable *1; Power adapter *1 |
| Shipping Info | Gift Box Dimension(mm): 205*140*50(mm); Carton Size(mm): 420*270*305 (mm）; Qty Per Carton(pcs): 20pcs; Gift Box.G.W(gs): 0.4Kg; Export carton (G.W.)(kgs): 8.9Kg |
Applications
- Home entertainment and 4K or 6K playback
- IPTV and OTT set-top use
- Hotel and guest room TV deployment
- Digital signage and office display
