Name: NDS3244S-24 24-Channel HDMI Encoder – 24 HDMI Inputs, H.264 Encoding – ANKVI
SKU: NDS3244S-24

Description

Overview

NDS3244S-24 is a 24-channel multi-channel HDMI encoder for professional HD/SD audio and video encoding, housed in a 440mm x 324mm x 44mm chassis. It carries 24 HDMI inputs, with every 8 HDMI ports sharing one encoder module, and each encoder module supporting 1 MPTS and 8 SPTS output.

Each module encodes to MPEG-4 AVC/H.264 with MPEG-1 Layer 2, LC-AAC, HE-AAC or AC3 pass-through audio and adjustable audio gain, and sends IP output over UDP and RTP/RTSP through the DATA (GE) port. Three encoder modules share one NMS port and one DATA port, and the unit is controlled and updated through its web management interface.

NDS3244S-24 Key Features

24 HDMI inputs with SPTS and MPTS output
8 HDMI ports share one encoder module, with 8 SPTS and 1 MPTS output per module
Three encoder modules share the same one NMS port and DATA port
MPEG-4 AVC/H.264 video encoding format
MPEG-1 Layer 2, LC-AAC and HE-AAC audio encoding, plus AC3 pass-through
Audio gain adjustable from 0 to 255
IP output over UDP and RTP/RTSP protocol
Supports QR code, LOGO and caption insertion
Supports the Null PKT Filter function
Web management control with easy updates over the web

NDS3244S-24 Specifications

Parameter	Specification
Input	24 HDMI inputs
Channel Count	24 channels
Encoder Modules	3 encoder modules, 8 HDMI inputs per module, sharing one NMS port and one DATA port
Video Encoding	MPEG-4 AVC/H.264
Video Input Resolution	1920x1080_60P, 1920x1080_60i, 1920x1080_50P, 1920x1080_50i, 1280x720_60P, 1280x720_50P, 720x576_50i, 720x480_60i
Video Output Resolution	1920x1080_30P, 1920x1080_25P, 1280x720_30P, 1280x720_25P, 720x576_25P, 720x480_30P
Bit Rate	1~20Mbps each channel
Rate Control	CBR/VBR
GOP Structure	IP…P (P frame adjustment, without B frame)
Audio Encoding	MPEG-1 Layer 2, LC-AAC, HE-AAC and AC3 pass-through
Audio Sampling Rate	48KHz
Audio Resolution	24-bit
Audio Gain	0-255 adjustable
MPEG-1 Layer 2 Bit Rate	48/56/64/80/96/112/128/160/192/224/256/320/384 kbps
LC-AAC Bit Rate	48/56/64/80/96/112/128/160/192/224/256/320/384 kbps
HE-AAC Bit Rate	48/56/64/80/96/112/128 kbps
Output	IP output through DATA (GE) over UDP and RTP/RTSP protocol
Multiplexing	8 HDMI inputs with 8 SPTS and 1 MPTS output for each encoder module
Management	Network management (WEB); English language; Ethernet software upgrade
Dimensions	440mm x 324mm x 44mm (W x L x H)
Operating Temperature	0~45C
Storage Temperature	-20~80C
Power Supply	AC 110V +-10%, 50/60Hz; AC 220V +-10%, 50/60Hz

Applications

Cable TV digital head-end systems
Digital TV broadcasting distribution
Encoding 24 HD/SD HDMI source channels into an IP transport stream network
Multi-channel SPTS and MPTS delivery over UDP or RTP/RTSP
